Industrial High Speed RGB Color Sensor IP66 Precise Detection Optical Sensor

Industrial High Speed RGB Color Sensor IP66 Precise Detection Optical Sensor
Industrial High Speed RGB Color Sensor IP66 Precise Detection Optical Sensor Industrial High Speed RGB Color Sensor IP66 Precise Detection Optical Sensor Industrial High Speed RGB Color Sensor IP66 Precise Detection Optical Sensor Industrial High Speed RGB Color Sensor IP66 Precise Detection Optical Sensor Industrial High Speed RGB Color Sensor IP66 Precise Detection Optical Sensor

Large Image :  Industrial High Speed RGB Color Sensor IP66 Precise Detection Optical Sensor

Product Details:
Place of Origin: Guangdong, China
Brand Name: BOJKE
Certification: CE
Model Number: BS-201ZWN
Document: BS-201ZWN specification 202...25.pdf
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: $36
Packaging Details: kraft box with carton box;
Delivery Time: 5~8 work days
Payment Terms: T/T
Supply Ability: 150k
Contact Now Chat Now

Industrial High Speed RGB Color Sensor IP66 Precise Detection Optical Sensor

Description
Product Name: RGB Color Sensor Usage: Color Detection On Production Lines
Theory: Light Emission Reflection Detection RGB Filterin Output: NPN/PNP
Response Time: <1ms Voltage - Supply: DC12~24V ±10%
Highlight:

Industrial RGB Color Sensor

,

High Speed RGB Color Sensor

,

RGB Color Sensor IP66

BOJKE Industrial High-Speed RGB Color Sensor IP66 Precise Detection Optical Sensor

Product Name Color Mark Sensor
Material PC
Function Detection and Recognize
Package Kraft box + inner box





Industrial High Speed RGB Color Sensor IP66 Precise Detection Optical Sensor 0



Model No BS-201ZWN BS-201ZWP
Product Picture
Operation Voltage  DC 12~24V ±10%
Consumption (no-load)  Current ≤35mA
Detection Range  17±5mm
Light Source  RGB color,  LED
Detection Mode  color mode and color mark mode switchable
Response Time < 1ms
Response Frequency   Color mode > 1000Hz； color mark mode > 1500Hz
 Output Type  NPN open collector  PNP open collector
Max Input Current <100mA
Residue Voltage <1.5V
Switch Type   Light.on/Dark.on switchable
Ambient Illumination  Incandescent lamp ≤ 3000Lux; Sunlight ≤ 10000Lux
Ambient Temperature operation:-10℃~55℃；storage:-25℃~75℃,no freezing
Ambient Humidity  operation: 35%~85% RH；storage:35%~95% RH no condensation
Protection Circuit polarity reversal protection/surge protection/short circuit protection
Protection Level IP67
Connection Type 4 core 2 meters standard cable
Housing Material PC
Vibration Resistance 10～55Hz, dual amplitude 1.0mm, X/Y/Z directions each 30 minute
Impact Resistance  300m/S², X,Y,Z directions each 3 times

Tag:

Color Mark Sensor,

Color Code Sensor,

Color Detection Sensor
