Industrial Color Sensor Photoelectric Color Mark Detection Packaging Machine Label LR Series Replacement

Industrial Color Sensor Photoelectric Color Mark Detection Packaging Machine Label LR Series Replacement
Industrial Color Sensor Photoelectric Color Mark Detection Packaging Machine Label LR Series Replacement Industrial Color Sensor Photoelectric Color Mark Detection Packaging Machine Label LR Series Replacement Industrial Color Sensor Photoelectric Color Mark Detection Packaging Machine Label LR Series Replacement

Large Image :  Industrial Color Sensor Photoelectric Color Mark Detection Packaging Machine Label LR Series Replacement

Product Details:
Place of Origin: Guangdong, China
Brand Name: BOJKE
Certification: CE
Model Number: BS-500NP
Document: BS-500NP user manual (2025....0).pdf
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: $68
Packaging Details: kraft paper box with carton box;
Delivery Time: 5~8 work days
Payment Terms: T/T
Supply Ability: 150k
Contact Now Chat Now

Industrial Color Sensor Photoelectric Color Mark Detection Packaging Machine Label LR Series Replacement

Description
Features: Contrast Sensors Name: Industrial Color Sensor
Product Name: White Light Spot Color Sensor Usage: Color Recognition
Output: NPN And PNP Response Time: 200us~500us
Voltage - Supply: 12~24V Detection Distance: 30~500mm
Supply Voltage: 12~24VDC 10%
Highlight:

CE Industrial Color Sensor

,

Industrial Color Detection Sensor

,

Photoelectric Color Mark Sensor

Industrial Colour Sensor Photoelectric Color Mark Detection Packaging Machine Label LR Series Replacement





Product Description
Product Name
Color Mark Sensor
Material
Aluminum alloy
Function
color detection and color recognition
Package
kraft box
Industrial Color Sensor Photoelectric Color Mark Detection Packaging Machine Label LR Series Replacement 0
  •

  • Product performance description

Easy to setting
30~500 mm long sensing distance
can adjust spot size.
Digital sensor, can sensing/ distinguish products/accurately distinguish others' different colors.
suitable for various scenarios

Model BS-500NP
Working Voltage DC12~24V ±10%
Cosumption current at 24V<60mA
Sensing range 30~500mm
Light Source white LED
Min light spot size Φ5mm when distance at 100mm; Φ26mm when distance at 500mm
Detection Mode C mode and MARK mode switchable
Response Time 200us/1ms/10ms/100ms/500ms swittchable
Output NPN/PNP switchable
Max load current 100mA
Residue voltage when 100mA:NPN ouput
  NO/NC switchable
Ambient Illumination Incandescent lamp: 20,000lux or less Sunlight:30,000lux or less
Ambient Temperature - 10 ~ +55℃ , no freezing
Ambient humidity 35%~85% RH no condensation
Protection circute polarity reversal protection/surge protection/short circuit protection
Protection level IP67
Connection type cable type(4 core cable length 2meter)
Housing material aluminum alloy
Vibration resistant 10 ~ 55Hz,double amplitude 1.5mm,2 hours in each of the X,Y,Z directions
Impact Resistance 300m/s2 (about 50G) X/Y/Z each direction 3 times
Weight about 100g(inlucde 2meter cable weight)


Q : What is the MOQ?
A : 1pcs for our own available designs
Q : Can I customize a special sensor?
A : Sure
Q : Can I get a lower price if I order large quantities?
A : Yes, Cheaper prices with bigger quantities orders
Q : Can I get a sample?
A : Of course, but you need to pay the sample fee
Q : When will you ship my order?
A : 3 day shipping guarantee for stock item and within 15 days for non-stock items.
Q : How about the quality guarantee period ?
A : Our warranty period is one year since from shipping date.
Q : Can I add or delete items from my order if I change mind?
A : Yes, but you need to tell us asap, if your order has been done in our production line, we cannot change it.
