PC Material Label Sensor U Slot Type PUD-050NP Label Counting Rewinding Machine

PC Material Label Sensor U Slot Type PUD-050NP Label Counting Rewinding Machine
PC Material Label Sensor U Slot Type PUD-050NP Label Counting Rewinding Machine PC Material Label Sensor U Slot Type PUD-050NP Label Counting Rewinding Machine PC Material Label Sensor U Slot Type PUD-050NP Label Counting Rewinding Machine PC Material Label Sensor U Slot Type PUD-050NP Label Counting Rewinding Machine PC Material Label Sensor U Slot Type PUD-050NP Label Counting Rewinding Machine PC Material Label Sensor U Slot Type PUD-050NP Label Counting Rewinding Machine

Large Image :  PC Material Label Sensor U Slot Type PUD-050NP Label Counting Rewinding Machine

Product Details:
Place of Origin: Guangdong, China
Brand Name: BOJKE
Certification: CE
Model Number: PUD-050NP
Document: PUD-050NP.pdf
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: $17.6
Packaging Details: PP bag with carton box;
Delivery Time: 5~8 work days
Payment Terms: T/T
Supply Ability: 150k
Contact Now Chat Now

PC Material Label Sensor U Slot Type PUD-050NP Label Counting Rewinding Machine

Description
Product Name: Label Sensor Manufacturer Part Number: PUD-050NP
Usage: Identification Tag Output: NPN/PNP
Response Time: <1ms Voltage - Supply: DC 12~24V ±10%
Highlight:

Label Sensor U Slot Type

,

PC Material Label Sensor

,

Label Sensor PUD-050NP



BOJKE Label Sensor U-Slot Type PUD-050NP Label Counting Rewinding Machine





Product Description

Product Name Label Sensor
Material PC
Function Identification Tag
Package Plastic box + inner box

PC Material Label Sensor U Slot Type PUD-050NP Label Counting Rewinding Machine 0
Model PUD-050NP
Detection Mode infrared sensing
Slot Wideth 2mm
Slot depth 41.5mm
Hysteresis Range <20%
Detection Object opaque label
Repeat Accuracy <5%
Sensitivity Adjustment button adjustable
Output Mode NPN and PNP two channel output at same time
Switch Mode NO/NC swtichable
Response Time <1ms
Response Frequency 10KHz
Working Voltage DC 12~24V ±10%
Residue Voltage <2V (load current 50mA, cable 2 meter)
Max Load Current 100mA
Consumption (no-load) current <40mA
Ambient Temperature working:-10℃~55℃；storage:-25℃~70℃,no freezing
Ambient Humidity working:35%~85% RH；storage:35%~95% RH,no condensation
Protection Circuit polarity reversal protection/surge protection/ short circuit protection
Protection Level IP64
Indicator Light Red: working indicator light;  Green: output indicator light
Connection Type cable-type (4 core, 2 meter standard cable)
Housing Material PC
Withstand Voltage AC 500V, 50/60Hz, 1 minute
Vibration Resistance 10～55Hz, dual amplitude 1.5mm, X/Y/Z directions each 2 hours
Impact Resistance 500m/S2, X,Y,Z directions each 3 times
Insulation Impedance  above 20MΩ (DC 500V megohmmeter)

Tag:

Capacitive Label Sensor,

Transparent Label Sensor,

Photo Electric Sensor
