Digital Pressure Switch Sensor High Precision Vacuum Gauge Positive Negative Pressure

Digital Pressure Switch Sensor High Precision Vacuum Gauge Positive Negative Pressure
Digital Pressure Switch Sensor High Precision Vacuum Gauge Positive Negative Pressure Digital Pressure Switch Sensor High Precision Vacuum Gauge Positive Negative Pressure Digital Pressure Switch Sensor High Precision Vacuum Gauge Positive Negative Pressure Digital Pressure Switch Sensor High Precision Vacuum Gauge Positive Negative Pressure Digital Pressure Switch Sensor High Precision Vacuum Gauge Positive Negative Pressure Digital Pressure Switch Sensor High Precision Vacuum Gauge Positive Negative Pressure

Large Image :  Digital Pressure Switch Sensor High Precision Vacuum Gauge Positive Negative Pressure

Product Details:
Place of Origin: Dongguan China
Brand Name: BOJKE
Certification: CE
Model Number: PS series
Document: pressure sensor-switch outp...ut.pdf
Payment & Shipping Terms:
Minimum Order Quantity: 1pcs
Price: $2.5
Packaging Details: PP bag with carton box;
Delivery Time: 5~8 work days
Payment Terms: T/T
Supply Ability: 150k
Contact Now Chat Now

Digital Pressure Switch Sensor High Precision Vacuum Gauge Positive Negative Pressure

Description
Power Supply: DC 12~24V Name: Pressure Switch Sensor
Highlight:

Digital Pressure Switch Sensor

,

Pressure Switch Sensor High Precision

,

Negative Pressure Switch Sensor

Digital Pressure Switch Sensor High Precision Vacuum Gauge Positive Negative Pressure





Product Name Pressure switch sensor
Material PBT and SUS303
Function Measure and indicate pressure
  •

  • Product performance description

1. Digital display
2. Analog output
3. low pressure and high pressure option
4. Quick threshold setting


Dual 2-color display makes operation easier!

"Current value" and "threshold value" can be checked at the same time!
Low pressure:-101.0~101.0kPa.
High pressure: -0.101~1.01MPa

Model R1/8+M5 female thread PS-1L-2N PS-1H-2N
M5 female thread PS-1L-2N-M5 PS-1H-2N-M5
Type  low pressure high pressure
Pressure Type standard pressure
Rated Pressure Range -100~+100KPa -0.1~1.0MPa
Setting Pressure Range  -101~+101KPa -0.101~1.01MPa
Pressure Resistance 500KPa 1.5MPa
Detectable Gas  non-corrosive Gas
Working Voltage  12-24VDC
Output Type  2 channel NPN open collector
Switch Mode  NO/NC settable
Hysteresis  1 digit
Repeat Accuracy  0.1%F.S.    <±2digits 0.2%F.S.    <±2digits
Response Time Min:2.5ms / Max:5000ms ,settable
  Current Consumption <30mA
  Max Input Current <100mA
  Residue Voltage  <2V
 Temperature Drift  <±0.5%F.S.(20℃) <±1%F.S.(20℃)
Ambient Temperature  Working temperature:-10℃~50℃；Storage temperature:-10℃~60℃(no freezing)
Ambient Temperature Humidity  Working humidity:35%~85% RH；Storage humidity:35%~85% RH(no condensation)
Housing Material PBT,the hole material of barometer:SUS303
Connection Type 2 meter 4 core standard cable
